L-1S
EBP INSTRUMENTS
Shanghai, Shenzhen, Ningbo
1000 sets
TT in advance
1 set
Main Application:
1. Die cavity of molds
2. Bearings and other parts
3. Failure analysis of pressure vessel, steam generator and
other equipment
4. Heavy work piece
5. The installed machinery and permanently assembled parts.
6. Testing surface of a small hollow space
7. Material identification in the warehouse of metallic materials
8. Rapid testing in large range and multi-measuring areas
for large-scale work piece
Technical Specifications:
Model | L-1S |
Measuring range | (170-960)HLD, (17-68.5)HRC, (19-651)HB, (80-976)HV, (30-100)HS, (59-85)HRA, (13-100)HRB |
Measuring direction | 360° (↓↖↗↘↙→←↑) |
Accuracy | ±6HLD |
Hardness Scale | HL, HB, HRB, HRC, HRA, HV, HS |
Display | segment LCD |
Data memory | max. 100 groups (relative to impact times 32-1) |
Working voltage | 3V (2 AA size alkaline battery) |
Continuous working period | about 100 hours (With backlight off) |
Communication interface |
|
Easy operation steps:
Packing list:
Name | No. | Item | Qty | Remarks |
Standard Configuration | 1 | Main unit | 1 | |
2 | D type impact device | 1 | With cable | |
3 | Standard test block | 1 | ||
4 | Cleaning brush (I) | 1 | ||
5 | Small support ring | 1 | ||
6 | Battery | 2 | AA size | |
7 | Manual book | 1 | ||
8 | Package case | 1 | ||
Optional Configuration | 9 | Cleaning brush | 1 | |
10 | Impact devices and support rings | DC / DL / D+15 / G / C | ||
11 | Data Pro software | 1 | ||
12 | Communication cable | 1 |
Main Application:
1. Die cavity of molds
2. Bearings and other parts
3. Failure analysis of pressure vessel, steam generator and
other equipment
4. Heavy work piece
5. The installed machinery and permanently assembled parts.
6. Testing surface of a small hollow space
7. Material identification in the warehouse of metallic materials
8. Rapid testing in large range and multi-measuring areas
for large-scale work piece
Technical Specifications:
Model | L-1S |
Measuring range | (170-960)HLD, (17-68.5)HRC, (19-651)HB, (80-976)HV, (30-100)HS, (59-85)HRA, (13-100)HRB |
Measuring direction | 360° (↓↖↗↘↙→←↑) |
Accuracy | ±6HLD |
Hardness Scale | HL, HB, HRB, HRC, HRA, HV, HS |
Display | segment LCD |
Data memory | max. 100 groups (relative to impact times 32-1) |
Working voltage | 3V (2 AA size alkaline battery) |
Continuous working period | about 100 hours (With backlight off) |
Communication interface |
|
Easy operation steps:
Packing list:
Name | No. | Item | Qty | Remarks |
Standard Configuration | 1 | Main unit | 1 | |
2 | D type impact device | 1 | With cable | |
3 | Standard test block | 1 | ||
4 | Cleaning brush (I) | 1 | ||
5 | Small support ring | 1 | ||
6 | Battery | 2 | AA size | |
7 | Manual book | 1 | ||
8 | Package case | 1 | ||
Optional Configuration | 9 | Cleaning brush | 1 | |
10 | Impact devices and support rings | DC / DL / D+15 / G / C | ||
11 | Data Pro software | 1 | ||
12 | Communication cable | 1 |
USB
