RV-150T
EBP INSTRUMENTS
Shanghai, Shenzhen, Ningbo
150 sets
TT in advance
1 set
Main Features:
1) Equipped superficial Rockwell, Rockwell, Vickers test methods;
2) 8 inch Touch-screen interface, easy to operate
3) Close loop, with high accuracy load cell, no need install weights;
4) Test force automatic correction, each file is automatically compensated force, improve the accuracy of the force a number of levels;
5) According to GB / ASTM hardness automatic conversion;
6) Rockwell automatically correct curvature radius;
7) Set a password to protect setup parameters, more samples and testing information;
8) Measuring U disk to save data to EXCEL format for easy editing and processing.
9) Modular design for easy maintenance.
Application range:
Suitable for hardened and surface hardened steel, hard alloy steel, casting parts, non-ferrous metals, various kinds of hardening and tempering steel and tempered steel, carburized steel sheet, soft metals, surface heat treating and chemical treating materials etc.
Technical Specification:
Model | RV-150T |
Rockwell Scales | HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRH, HRK, HRL, HRM, HRP, HRR, HRS, HRV |
Superficial Rockwell Scale | HR15N, HR30N, HR45N, HR15T, HR30T, HR45T |
Vickers Scale | HV5, HV10, HV20, HV30, HV40, HV50, HV60, HV80, HV100, HV120 |
Test force | Rockwell: 60kgf(588N), 100kgf(980N), 150kgf(1471N); Initial test force:10kgf(98N); Superficial Rockwell: 15kgf (147.1N) 30kgf (294.2N) 45kgf (441.3N), Initial test force: 3kgf (29.4N) Vickers: 5kgf(49N), 10kgf(98N), 20kgf(196N), 30kgf(294N), 40kgf(392N), 50kgf(490N), 60kgf(588N), 80kgf(784N), 100kgf(980N), 120kgf(1176N) |
Hardness range | Rockwell: 20-100HR; Vickers: 8-2900HV |
Force error | ＜0.5% |
Holding Time | 1-99s |
Minimum measuring unit | 0.1µm |
Allowed maximum sample size (test space) | Allowed max. Sample height in vertical: 220mm(for Rockwell); 150mm(for Vickers test mode); Allowed max. Sample height in horizontal: 200mm |
Magnification | Eyepiece: 15X, 5X (for Vickers) (10X, 20X for optional) Total magnification: 75X |
Hardness read | Touchable LCD display, USB Flash Disk |
Power supply | AC220V, 50-60Hz |
Implementation of the standards | ISO 6508, ASTM E-18, JIS Z2245, GB/T 230.2 ASTM E384 & E92, EN-ISO 6507-2, JIS B-7734, GB/T4340 |
Dimensions | Machine size: 560*350*800mm Packing size: 730x450x910mm |
Weight | N/W: 70kg; G/W: 99kg |
Packing List:
Part name | Quantity | Name | Quantity |
15X eyepiece | 1 | Objective Lens 5x | 1 |
Vickers indenter | 1 | Rockwell 1.588 carbide ball indenter | 1 |
Rockwell diamond indenter | 1 | Hardness block | 5pcs |
Power line | 1 | lighting | 1 |
Sliding test sets | 1 | Large, medium, V-test sets | 1 each |
Fuse 2A | 2 | U disk (with an Operation manual) | 1 |
Dust proof cover | 1 | Adjust level screw | 4 |
Manual book | 1 | Accessory box | 1 |
