High Resolution Auto Focus Video Measuring Microscope

0.7-4.5X parallel continue zoom lens;
It can measure straight lines, angles, concentric circles, parallel lines, point-to-line distance, point and line to concentric circles, diameter, circumference and area, length and width of rectangle, and can calculate circumference and area;
It can measure the polygon and calculate its area. All the corresponding measurement report can be output to U disk.
  • VM-500
  • EBP INSTRUMENTS
  • Shanghai, China
  • 300 Sets Per Month
  • T/T in advance
  • 1 set

Application:

It can be applied to incoming inspection, production inspection, material research, PCB and SMT inspection analysis, printing, textile inspection, biological anatomy, medical testing and other fields.

measuring microscope


Product Characteristics:

1) Integral design, exquisite, fashion, generous;

2) Built-in high-definition HDMI integrated camera, directly connected to HDMI display, can take pictures or videos;

3) With high definition 0.7~4.5X parallel continue zoom lens, it is much more convenience and fast to switch objective magnification;

4) With adjustable LED surface reflection illumination, is able to control brightness independently;

5) With 2 mega pixel auto focus camera, no need to waste time for manual focus frequently;

6) Multiple optional mobile control platform, ensure precision position measurement;

7) With its own measurement function, it can measure linear dimensions such as distance, perimeter, area, angle, radian, width, height, and radius elements.



Technical Specification:

Model

VM-500

Electronic Magnification

32X-206X ( HDMI 16:9 24”Monitor)

Optical Objective

0.7X~4.5X Zoom Lens

Zoom ratio:6.5:1

0.5X C-mount camera adapter mirror

Camera Parameters

2M Pixel (1920*1080)

Image Size:1/2.8”

Frames:1080P@60fps

Measuring Function

Linear dimensions such as distance, perimeter, area, angle, radian, width, height, and radius elements are measured

Measurement Accuracy

0.02mm~0.003mm

Illumination

Adjustable LED Surface Illumination

Microscope Stand

Z-axis Travel: 100mm

Electrical Parameters

AC90~240V/50~60HZ

Dimension

375*285*500 mm

Weight

6.5Kg


Measurement Function Introduction

VM-500 can measure straight lines, angles, concentric circles, parallel lines, point-to-line distance, point and line to concentric circles, diameter, circumference and area, length and width of rectangle, and can calculate circumference and area. It can measure the polygon and calculate its area. All the corresponding measurement report can be output to U disk.

video measuring microscope


Field of View:

Optical Magnification

Actual effective field of view (X, Y, D: mm)

0.7x

17.76

10.03

20.40

1x

11.16

6.3

12.82

2x

5.42

3.06

6.22

3x

3.63

2.05

4.17

4x

2.7

1.52

3.10

4.5x

2.47

1.4

2.84


Standard Accessories:

Item

Name

Quantity

1

Main Body VM-500

1

2

DELL Monitor

1

3

Power Cable

1

4

Wireless Mouse

1

5

U-disk 16G

1

6

Manual Book / Packing list

1

7

Warranty Card

1

8

Qualified Certificate

1


Optional Accessories:

microscope lens
